VLX 100 Pivot Door

VLX 100 Pivot Door in San Diego, CA | Westlight Windows San Diego

The VLX 100 Pivot Door is a heavy-duty aluminum entry system that rotates on a vertical center axis instead of swinging on side hinges. It’s the door you install when the entry itself is meant to be the architectural moment: oversized glass, clean lines, and a pivot point that lets a 60-inch-wide panel open with surprising ease. Westlight Windows San Diego is an authorized installation partner for ViewLux, the manufacturer of the VLX 100. That matters because this door is only as good as the crew that sets it. Call (619) 793-3829 to talk through sizes, glass packages, and a real installation timeline for your San Diego home.

Call (619) 793-3829

Product Overview – VLX 100 Pivot Door

The VLX 100 is built around one idea: the door as a design statement, not an afterthought. The panel rotates on a vertical axis placed off to one side, which means the door can be much wider than a conventional hinged door without sagging or becoming impossible to operate. We regularly install these on contemporary homes in La Jolla, Del Mar, Bankers Hill, and Point Loma where the front entry sets the tone for the rest of the house.

The frame and panel are extruded aluminum. That’s the right material for San Diego’s coastal climate, which means salt air, strong sun, and big temperature swings between day and night. The aluminum won’t warp the way solid wood does in ocean-adjacent neighborhoods, and it holds its shape far better than vinyl under direct sun exposure. The engineering tolerances are tight: wall thickness of 0.098″ and a profile width of 2.56″ mean you’re getting a door that feels substantial when it closes, not hollow.

Why do buyers choose the VLX 100 over a standard hinged entry door? Three reasons come up most often in our showroom conversations. First, size: the VLX 100 supports panels up to 60 inches wide and 120 inches tall, which is dramatically larger than any side-hinged door can handle. Second, glass area: with the hardware integrated into the frame rather than attached to the face, the glass reads as one uninterrupted plane. Third, the pivot motion itself: there’s a physical satisfaction to a door that swings around a center axis that you simply don’t get from a conventional hinge. In San Diego, where indoor-outdoor living is the default, that matters.

Westlight Windows San Diego has installed these doors in everything from new-build coastal modern homes to mid-century remodels in Mission Hills. We’ve also walked homeowners through honestly evaluating whether a pivot door is the right choice for their project. It’s not for every entry, and we’ll tell you that up front. For the right home, there’s nothing else like it.

Technical Specifications

The VLX 100 spec sheet is straightforward, and we’ll break it down here in plain terms rather than engineering shorthand.

• Wall thickness: 0.098″ extruded aluminum. This gives the frame real structural stiffness without adding unnecessary weight.
• Profile width: 2.56″. Slim enough to keep sightlines clean, wide enough to house proper thermal breaks and weather seals.
• Maximum span: Up to 60″ wide × 120″ tall. That’s a full 5 feet of glass width and 10 feet of height. On most San Diego homes, that’s a genuinely monumental entry.
• Glass options: Clear, frosted, obscure, Low-E, tempered, and laminated. Each serves a different combination of light, privacy, energy, and impact needs.
• Finish options: Premium Black, Pure White, Anodized Silver, Bronze, Champagne, and Teak Wood. These are durable coating systems designed for exterior exposure, not interior-grade paint.

All glass for the VLX 100 is supplied as insulated units, which means the door carries real thermal performance numbers. We specify the exact glass package based on the home’s exposure, the coastal zone, and the homeowner’s privacy priorities.

Performance Features

Thermal Efficiency – The VLX 100 uses thermal break technology to separate the interior and exterior aluminum faces. That break prevents heat from conducting directly through the frame, which is the classic weakness of aluminum windows and doors. With Low-E coated glass, you get an NFRC-rated assembly that handles San Diego’s hot inland summers and cool coastal evenings without turning your entry into an energy leak.

Acoustic Performance – The frame’s seal system and the mass of laminated glass options work together to cut exterior noise. We hear this need constantly from homeowners near Friars Road, the 5, or the flight path into Lindbergh. You cannot eliminate all exterior noise, but a properly sealed aluminum pivot door outperforms most entry doors we replace.

Airtightness & Weather Seal – The VLX 100’s multi-point locking system pulls the entire panel against continuous weatherstripping when engaged. That matters for drafts and it matters for dust. On days when Santa Ana winds kick up, a standard door with a single latch point lets dust and air slip through the corners. The VLX 100 does not behave that way.

Waterproofing – Aluminum doesn’t rot, but a poorly installed aluminum door leaks just fine. The VLX 100’s drainage system is built into the extrusion design. Water that gets past the outer gasket is channeled out through weep paths rather than pooling inside the frame. It’s a detail you never see but you definitely experience if it’s missing.

Wind Resistance – The VLX 100 is engineered and rated for wind loads that meet San Diego County’s structural requirements, including coastal zones. The heavy aluminum panel, coupled with a reinforced frame and substantial pivot hardware, handles gusty conditions that make flimsier doors flex and whistle. For homes east of the 15, this matters on every Santa Ana day.

Security & Hardware – The pivot hinge itself is a heavy concealed unit rated for exactly what this door demands. The lock system isn’t a single throw bolt. It’s a multi-point arrangement that secures the panel at the top, bottom, and center. Combine that with laminated, impact-resistant glass and you have a door that genuinely resists forced entry, not just visually.

Color & Glass Options

The VLX 100 finish palette covers the range we most commonly see in San Diego architecture. Premium Black is the default choice for modern coastal builds and works beautifully against white stucco or light wood siding. Pure White fits cleanly into the more traditional neighborhoods like Kensington or Talmadge where bright exteriors dominate. Anodized Silver gives that honest metallic look that pairs with industrial and steel details, and it holds up remarkably well within view of the ocean. Bronze and Champagne are warmer metallics that suit homes with gold or copper fixtures and earth-tone exteriors. Teak Wood is a wood-grain finish that reads as warm timber from ten feet away but never cracks, peels, or needs refinishing.

Glass choice is driven by three questions: how much light, how much privacy, how much safety. Clear tempered glass maximizes daylight and unobstructed views. Frosted glass scatters light while blocking direct sightlines. Obscure glass goes further, giving you genuine privacy for bathrooms, wine rooms, or street-facing entries. Low-E coatings cut solar heat gain and UV exposure, which protects flooring and furniture. Tempered glass is safety glass, required by code and essential for any door. Laminated glass is the upgrade we recommend on every pivot door: it holds together if shattered, it blocks more noise, and it delivers meaningful impact resistance for homes in fire-prone zones or on busy streets.

Installation by Westlight Windows San Diego in San Diego

Installation is where a great pivot door becomes a problem or a pleasure. We’ve pulled out pivot doors installed by generalist crews that leaked by the first rain. It happens because a pivot door is not forgiving. The rough opening must be dead square. The door must be set level, plumb, and true, not just close enough to look right on move-in day. If the frame is racked even slightly, the panel will drift, the seals will gap, and the warranty dies.

Westlight Windows San Diego installs the VLX 100 to AAMA 2400/2410 installation standards. That’s the recognized industry practice for exterior glass and glazing installation. It covers the methods that keep air, water, and structural settlement from destroying a door over time. We also use AAMA 812 low-expansion foam sealant on every perimeter joint. That’s the right product for this work: it seals the rough opening fully, it doesn’t expand enough to distort the frame, and it doesn’t shrink or crack the way caulk-only installs do.

Our process starts with a pre-installation inspection of the rough opening. We check dimensions along both diagonals, verify the substrate, and address any structural issues before the door ever arrives. On installation day, we set the frame with shims and a laser level, secure it per ViewLux’s specifications, foam-seal the perimeter, apply the exterior moisture barrier and flashing, install the panel, adjust the pivot and latches, and then run a full water test. We don’t leave until the door opens and closes with one hand and the seals are touching everywhere they should.

San Diego gets less rain than most of the country, but when it rains it can come hard, and the years of salt air, heat, and UV do their own kind of damage. A properly installed VLX 100 faces both without the slow failures that come from sloppy work. And it keeps your manufacturer warranty intact, which matters when you’re investing at this level. Call (619) 793-3829 if you’d like to schedule a site assessment.

Frequently Asked Questions – VLX 100 Pivot Door

What is the lead time for the VLX 100 Pivot Door? The VLX 100 is typically built to order with a lead time of 6 to 10 weeks from final drawing approval, depending on the glass package and finish selected. Standard finishes and clear glass move faster. Call (619) 793-3829 for a current estimate once we know your door size and options.

Does the VLX 100 qualify for energy tax credits? The VLX 100 may qualify for federal energy efficiency tax credits when configured with a qualifying Low-E glass package that meets the applicable ratings for the climate zone covering San Diego. We’ll specify your glass and provide the documentation. The credit eligibility depends on the exact configuration and current tax rules, so call (619) 793-3829 to review your project.

What warranty comes with the Pivot Door? ViewLux provides a manufacturer warranty on the VLX 100 frame, glass, and hardware. The warranty is contingent on installation by an authorized partner following the manufacturer’s specifications and AAMA standard practice, which is exactly how Westlight Windows San Diego installs every pivot door. Call (619) 793-3829 for full warranty documentation.

Can I customize the size of the VLX 100? Yes, the VLX 100 is built around your rough opening, not the other way around. The maximum panel span is 60 inches wide by 120 inches tall, and we can order any dimension up to that limit in standard increments. Odd sizes are common in San Diego remodels, and the VLX 100 accommodates them. Call (619) 793-3829 for a free measurement.

How do I maintain aluminum frames and the pivot hardware? Aluminum frames need almost nothing: wash with mild soap and water, rinse, and occasionally apply a dry silicone lubricant to the weather seals. The pivot hardware should be checked annually for smooth operation, and any adjustment should be done by a professional. We’re happy to answer a maintenance question by phone: (619) 793-3829.

Get a Quote – VLX 100 Pivot Door in San Diego

If you’re planning an entry that deserves a pivot door, we’d like to measure and talk through your options. We’ll bring glass samples, finish swatches, and a clear written quote. Call Westlight Windows San Diego at (619) 793-3829 to start your project.

Written by the team at Westlight Windows San Diego, authorized ViewLux installation partner serving San Diego, CA.
